RAFIX 22 FS+, keylock switch SSG10, collar round, frontring metallic silver, 1 x 40°, momentary contact function, key removal position 0

Article number: 1.30.275.821/0000

Coming soon

Technical data

General
Disassembly possible	no
Scope of delivery	1 Key
Color	dark gray
Collar color	dark gray
Front ring color	metallic silver
Collar shape	round
Operating temperature, min.	-25 °C
Operating temperature, max.	70 °C
Storage temperature, min.	-40 °C
Storage temperature, max.	80 °C
illuminated	No
Packaging	Box
Packaging unit	2 pcs.
Operating life	50,000 cycles
B10	71,660 cycles
Degree of protection, front side, according to DIN EN 60529	IP65
Minimum order quantity (MOQ)	10 pcs.
RoHS compliant	Yes
REACH compliant	Yes
Country of origin	HU
Mounting dimensions
Outside dimension, length	29.8 mm
Outside dimension, width	29.8 mm
Outside dimension, height	56.9 mm
Mounting hole	22.3 mm
Mounting depth	9.2 mm
Installation height	48.3 mm
Grid, min.	30 x 30 mm
Mechanical characteristics
Key removal position	0
Number of locking positions	1
Fixing	Threaded ring
Actuation function	momentary contact function
Operating torque, max.	1.3 Nm
Threaded ring torque, max.	1.2 Nm
Rotating angle	1 x 40°
Resistance to force on the side	100 N
Locking position	SSG10

Specifications according to UL 60947
UL Enclosure Type Rating front side	type 1 type 4X indoor

Drawings

Dimensioned drawing

System drawing

Mounting hole drawing

front panel drawing

Description

The locking systems we use were developed by renowned lock manufacturers in accordance with the DIN EN 1303 standard. They are open, mechanical systems which, depending on the environmental conditions, require occasional maintenance (e.g. greasing) by the machine or system operator.
We have developed and fully qualified our key switches with RAFI reference keys. Under certain circumstances, plant operators may be using various low-cost key copies or third-party keys whose function and tactility may differ.

The key switch "SSG10" Is authorized and mainly used in industrial plants for the automotive industry. The scope of delivery includes one key.
