E-BOX MODULAR, housing, 35 V, 22.3 mm, M20 on bottom, yellow
Article number: 1.20.810.311/0000
Technical data
| Color | yellow |
| Operating temperature, min. | -25 °C |
| Operating temperature, max. | 70 °C |
| Storage temperature, min. | -40 °C |
| Storage temperature, max. | 80 °C |
| Packaging | Box |
| Packaging unit | 1 pcs. |
| net weight | 100.8 g |
| Degree of protection, front side, according to DIN EN 60529 | IP65 |
| Degree of protection, rear side, according to DIN EN 60529 | IP65 |
| Protection class | II |
| Minimum order quantity (MOQ) | 5 pcs. |
| RoHS compliant | Yes |
| REACH compliant | Yes |
| Outside dimension, length | 108,6 mm |
| Outside dimension, width | 40 mm |
| Outside dimension, height | 27 mm |
| Mounting hole | 22.3 mm |
| Fixing | Assembly clip |
| Terminal on the rear | M20 on bottom |
| Operating voltage, max. | 35 V |
Drawings
Dimensioned drawing
System drawing
System drawing
System drawing
Description
The elegant and flat E-BOX is the complete housing for RAFIX 22 FS+ control units. It is used where individual control devices are required at remote locations - for example, emergency stop applications along a production facility or at a safety fence. The compact dimensions of the E-BOX are based on the edge dimensions of a 40 mm profile rail. Installation is also designed with this in mind. This is quick and easy thanks to the modular system consisting of a lower and upper housing section, contact module with switching element and actuator.
3D viewer
Downloads
CAD_3D_EBOX-FS-120810310--80
CP65 Document
Declaration of conformity
POP Document
RoHS
SVHC Document
TSCA Document
UL certificate
VDE certificate
Assembly Instructions
Brochure
Chemical resistance
EPLAN EDZ RAFI complete
Switching elements
E-BOX MODULAR, emergency stop contact module, 35 V
Required accessories
RAFIX 22 FS+, emergency stop
RAFIX 22 FS+, emergency stop compact
