Keylock switch, 16.2 mm, round collar, 1 NO, Gold, Solder terminal, 2 x 90°, latching, key removal position 0+1+2

Article number: 1.10.116.713/0000

Discontinued

General
Collar shape	round
Operating temperature, min.	-25 °C
Operating temperature, max.	70 °C
Storage temperature, min.	-40 °C
Storage temperature, max.	80 °C
illuminated	No
Soldering time for manual soldering, max.	3 sec
Soldering temperature for manual soldering	350 °C
Soldering	Manual soldering
Packaging	Box
Packaging unit	2 pcs.
Operating life	50,000 cycles
B10	65,000 cycles
MOQ order	10 pcs.
RoHS compliant	Yes
REACH compliant	Yes
Mounting dimensions
Outside dimension, length	18 mm
Outside dimension, width	18 mm
Mounting hole	16.2 mm
Mounting depth	39.5 mm
Installation height	7.5 mm
Collar dimension	18 mm
Mechanical characteristics
Actuation function	latching
Operating torque, max.	1.8 Nm
Contact function	1 NO
Contact system	Bridge-sliding contact
Contact material	Gold
Locking position	001
Key lock	Micromec
Key removal position	0+1+2
Rotating angle	2 x 90°
Fixing	Threaded ring
Solderability	Yes
Threaded ring torque, max.	0.8 Nm
Terminal on the rear	Solder terminal
