Priority keylock switch, 16.2 mm, Rectangular Collar, 1 NO, Gold, Solder terminal, 3 x 90°, latching, key removal position 0
Article number: 1.10.117.117/0000
Discontinued
Technical data
| Collar shape | rectangular |
| Operating temperature, min. | -25 °C |
| Operating temperature, max. | 70 °C |
| Storage temperature, min. | -40 °C |
| Storage temperature, max. | 80 °C |
| illuminated | No |
| Soldering time for manual soldering, max. | 3 sec |
| Soldering temperature for manual soldering | 350 °C |
| Soldering | Manual soldering |
| Packaging | Box |
| Packaging unit | 2 pcs. |
| net weight | 21.9 g |
| Operating life | 50,000 cycles |
| B10 | 65,000 cycles |
| MOQ order | 10 pcs. |
| RoHS compliant | Yes |
| REACH compliant | Yes |
| Outside dimension, length | 24 mm |
| Outside dimension, width | 18 mm |
| Mounting hole | 16.2 mm |
| Mounting depth | 39.5 mm |
| Installation height | 7.5 mm |
| Actuation function | latching |
| Operating torque, max. | 1.8 Nm |
| Contact function | 1 NO |
| Contact system | Bridge-sliding contact |
| Contact material | Gold |
| Locking position | 001 |
| Key lock | Micromec |
| Key removal position | 0 |
| Rotating angle | 3 x 90° |
| Fixing | Threaded ring |
| Solderability | Yes |
| Threaded ring torque, max. | 0.8 Nm |
| Terminal on the rear | Solder terminal |
| Rated voltage, min. | 5 V |
| Rated voltage, max. | 35 V |
| Rated current, min. |
|
| Rated current, max. |
|
Description
Depending on the key, different switch positions are permitted: Key 1 switches to lock position 1, key 2 to lock position 1 and 2, etc...
Scope of delivery: 2 x 90° → 2 keys, 3 x 90° → 3 keys.
3D viewer
Downloads
CAD_3D_110117117-00
CP65 Document
POP Document
RoHS
SVHC Document
TSCA Document
Product discontinuation
