RAMO 30 EDGE

Article number: 5.04.013.042/0000

Technical data

General
Packaging unit	2 pcs.
net weight	35.6 g
MOQ order	2 pcs.
RoHS compliant	Yes
REACH compliant	Yes

Mounting dimensions
Outside dimension, length	45 mm
Outside dimension, width	40 mm
Outside dimension, height	40 mm
Mounting hole	30.3 mm
Grid, min.	40 mm
Mechanical characteristics
Resistance to force on the side	100 N

Drawings

Dimensioned drawing

Description

With the EDGE mounting bracket, the RAMO can be mounted on profiles and without additional insulating material housing. This offers freedom in mounting and new possibilities to place the components away from the central machine or device control panel.
