MICON 5 SAFETY, SMT standard, 5.6 ± 1.1 N, 1 NC + 1 NO
Article number: 1.14.205.111/0000
Technical data
| Operating temperature, min. | -40 °C |
| Operating temperature, max. | 125 °C |
| Storage temperature, min. | -40 °C |
| Storage temperature, max. | 90 °C |
| illuminated | No |
| Soldering | Reflow |
| Solder heat resistance according to standard |
DIN EN 60068-2-58
DIN EN 61760-1 |
| Packaging | Blister |
| Packaging unit | 2,100 pcs. |
| Operating life | 1,000,000 cycles |
| B10 | 1,300,000 cycles |
| Degree of protection, front side, according to ISO 20653 | IP67 (IP6K7) |
| Degree of protection on rear side acc. to ISO 20653 | IP67 (IP6K7) |
| MSL Moisture Sensitivity Level | 1 |
| Shock resistance according to standard IEC 60068-2-27 | 50 g at 11 ms amplitude semi-sinusoidal |
| Oscillation restistance according to standard IEC 60068-2-6 | 5 g at 10...500 Hz |
| Minimum order quantity (MOQ) | 2,100 pcs. |
| RoHS compliant | Yes |
| REACH compliant | Yes |
| Product code | WW |
| Outside dimension, length | 6.4 ± 0.1 mm |
| Outside dimension, width | 5.1 ± 0.1 mm |
| Installation height | 3.85 ± 0.1 mm |
| Grid, min. | 6 x 7.8 mm |
| Terminal on the rear | SMT |
| Actuation function | momentary contact function |
| Operating force, max. | 8 N |
| Operating force, min. | 5.6 ± 1.1 N |
| Contact function | 1 NC + 1 NO |
| Contact system |
Snap-action contact
DPST - Double Pole Single Throw |
| Contact material | Gold |
| Solderability | Yes |
| Bounce time at 10 mm/s | <5 ms |
| Switching function | Break before make |
| Switching travel | 0.9 ± 0.15 mm |
| Rated voltage, min. |
|
| Rated voltage, max. | 35 V |
| Dielectric strength | 250 V |
| Rated current, min. |
|
| Rated current, max. |
|
| Rated power, max. | 1 W |
Drawings
Dimensioned drawing
System drawing
PCB drawing
PCB drawing
Schematic diagram
Product labeling drawing
Packaging drawing
Packaging drawing
Connection drawing
Force-travel diagram
Description
MICON 5 tactile switches offer extreme switching reliability, with a very small space requirement. They can be arranged individually, in rows or as key blocks. For use beneath overlays, we recommend combining the MICON 5 tactile switches with plungers. Here are the properties at a glance:
- Suitable for the most important soldering techniques
- Soldering bath for THT versions
- Reflow soldering for SMT versions
- Vapor phase soldering for SMT versions
- Manual soldering
- Processing of the SMT design with SMT automatic assembly machines
- IMDS entry
- Packaging in blister tape, spool with 2,100 pieces
- Proposal for stencil printing: 150 µm stencil with 10% pad reduction on area
MICON 5 SAFETY - Note on Safety-Critical Applications:
The MICON 5 SAFETY is an electromechanical tactile switch based on snap-disc technology. Due to the nature of this technology, electromechanical components of this type exhibit a limited early failure characteristic, which must be managed through system-level measures.
When integrating the product into safety-critical functions, the user is required to take this characteristic into account as part of the risk assessment for the entire system. Responsibility for the product's suitability within the respective safety circuit remains with the system integrator.
