E-BOX XL MODULAR, housing, 4 installation points, 22.3 mm, M20 to the side, light gray
Article number: 1.20.810.540/0000
Technical data
| Installation points | 4 pcs. |
| Color | light gray |
| Operating temperature, min. | -25 °C |
| Operating temperature, max. | 70 °C |
| Storage temperature, min. | -40 °C |
| Storage temperature, max. | 80 °C |
| Packaging | Box |
| Packaging unit | 1 pcs. |
| Degree of protection, front side, according to DIN EN 60529 | IP65 |
| Degree of protection, rear side, according to DIN EN 60529 | IP65 |
| Protection class | II |
| MOQ order | 5 pcs. |
| RoHS compliant | Yes |
| REACH compliant | Yes |
| Outside dimension, length | 266 mm |
| Outside dimension, width | 40 mm |
| Mounting hole | 22.3 mm |
| Fixing | Screw |
| Terminal on the rear | M20 to the side |
Description
Main areas of application
- Measurement-control-regulation
- Mechanical and system engineering
- Construction machinery
- Industrial robots
- Model construction
- Home technology
Downloads
Chemical resistance
CP65 Document
POP Document
RoHS
SVHC Document
TSCA Document
